Golf Cart Controller 1266-5201 1266A-5201 36-48V 275A

Description

36–48V 275A Golf Cart Motor Controller — Replaces Curtis 1266-5201 / 1266A-5201

This aftermarket replacement motor controller is for 36–48 volt electric golf carts that use a Curtis 1266-5201 or 1266A-5201 controller. It is rated 275 amps. Common signs of a failing controller are no movement, jerky or weak acceleration, cutting out on hills, or the controller getting very hot.

Will it fit my cart?

• 36–48V electric golf carts that use a Curtis 1266-5201 or 1266A-5201 controller (check the label on your old controller)
• Club Car electric carts (per our listing; compare the label first)
• Not for gas carts
• Not sure? Compare the part number on your old controller, or send a photo on WhatsApp to +1 (213) 551-9059 and we’ll check it for you.

Specifications

• Model: 1266-5201 / 1266A-5201 type
• Voltage: 36–48V
• Current: 275A
• Package: 1 piece, 10.51 x 7.48 x 4.72 inches, 2 kg (4.4 lb)

Installation — difficulty: advanced (about 1–2 hours)

1. Put the Tow/Run switch in TOW and disconnect the main negative battery cable.
2. Take clear photos of every cable and wire on the old controller and label them.
3. Disconnect the cables and wires, then unbolt the old controller.
4. Mount the new controller in the same place and reconnect everything exactly as in your photos.
5. Reconnect the battery, lift the drive wheels off the ground and test forward and reverse slowly before driving.
6. If you are not comfortable doing this job, have a golf cart mechanic install it.

What’s in the Box

• 1 x motor controller

Warranty

1-year warranty and 30-day returns on uninstalled parts. Ships from our US warehouse.
